This shade is built from parallel vertical slats gathered into a narrow cylinder. Their lower ends step along a diagonal line, giving the bottom an angled profile rather than a level rim. Thin horizontal supports hold the ribs in the reference. Several format variants accompany the single project preview.
This free library entry is identified as LLN-000096. Use the real project preview to choose the design, then inspect the source vectors before committing material. Preview colors, room mock-ups and photographed builds may differ from the lines and pieces in the cutting files.
What is in the project folder?
The extracted folder contains 15 design files: 3 AI, 3 CDR, 3 DXF, 3 EPS, 3 SVG. It also includes 1 preview image. The universal library disclaimer, where present, is not a design or an assembly manual.
These are the formats actually present in this folder—not a promise that every format works in every laser or graphics program. Open a file in your own software and inspect its units, scale, layers and cut-versus-engrave paths before production.
Prepare this design carefully
Identify the shortest and longest ribs and preserve their sequence around the cylinder. Check the support-ring positions and slot clearances with a trial fit. Source variants may differ in scale or allowance; inspect them rather than combining files. Assess the chosen bulb's heat and clearance separately from the shade pattern.
Make a small test with your own material and machine settings. The library has not independently verified thickness, kerf, strength, electrical performance, load capacity or machine compatibility for this project. If the design includes text, tiny bridges or interlocking parts, examine them at the final intended size.
Before final production, save an untouched source copy, inspect imported geometry for missing curves, and compare the first test piece with the supplied reference image.
